Festo Soft Stop SPC11 Series User Manual

4. Commissioning
4-34
Festo P.BE-SPC11-SYS-ASI -EN en 0203NH
You can move the mass into the saved end positions or
intermediate positions with the input bits P.01...P.04. When
an end position is reached, the moveable mass will be
pressed against the stop with a pressure equal at maximum
to the operating pressure. When a n intermediate position is
reached, the moveable mass stands closed-loop controlled in
that position.
Input bit
Description
D0: P.01 I1 If the input bits P.02, P.03 and P.04 supply a 0- signal (0 V), the positioning order
to move to end po s ition P.01 will be sent by a 1-signal at these input bits.
1)
D1: P.02 I2 If the input bits P.01, P.03 and P.04 supply a 0- signal (0 V), the positioning order
to move to end po s ition P.02 will be sent by a 1-signal at these input bits.
1)
D2: P.03 I3 If the input bits P.01, P.03 and P.04 supply a 0- signal (0 V), the positioning order
to move to the taught intermediate position P.03 will be sent by a 1-signal at
these input bits.
1)
D3: P.04 I4 If the input bits P.01, P.02 and P.03 supply a 0-signal (0 V), the positioning order
to move to the taught intermediate position P.04 will be sent by a 1-signal at
these input bits.
1)
1) A change of direction is possible at any time. Positioning tasks must be clear. If 2, 3 or all 4 bits are
set, there will be n o reaction.

Festo Soft Stop SPC11 Series Specifications

General

Input Voltage	24 V DC
Output Current	0.5 A
Operating Pressure	6 bar
Ambient Temperature	20 °C
Connection Size	G1/4
Nominal Current Consumption	0.1 A
Ambient Temperature Range	0 to 50 °C
