Flexball Italiana S.r.l. 49
11.3. Actuator parameters
Parameters are different in relation of the kind of actuator and application. The detailed parameter list is
described in section for the specific application. Here bewol are listed the parameters present in any type of
actuator.
Code
display
Description Values
Factory
value
Value shown on
display (factory value)
Note
A0
Push-pull cable movement
direction
1 .. 4 4 4
dI
Delay before disengaging
the gearbox
0 .. 9,9 s 0,0 s 0
dA Delay on the throttle 0 .. 9,9 s 0,0 s 0
CC To be used for the check-up of the internal CANBus communication
11.3.1. Parameter “CC”
With this parameter you can check if the communication between the command station and the actuator is
correct. The value of the parameter corresponds to a precise physical position of the lever and it is described in
the following table:
Value shown
on display
Description
N
indicates that the command station is in neutral position
F
indicates that the command station is in forward position
R
indicates that the command station is in rear position
1-2-3-4-…..-9-A
indicates that the command station is in throttle condition: “1” is the
position of minimum gas and “A” is the position of maximum gas
► Important: for systems where the actuator commands only one engine, the values displayed are according
to the following picture:
Parameters referring
to the right engine
Parameters referring
to the left engine
It is shown an underscore “_” or
the right lever position if it is the
actuator of the left engine
It is shown an underscore “_”
or the left lever position if it is
the actuator of the left engine
