Flexball Italiana S.r.l. 53
After having set the stroke positions, it might happen that there is not the right correspondence between the
direction of the lever and the movement executed by the actuator (e.g.: you move the lever forward and the
gearbox cable pushing instead of pulling). Changing the value of parameter A0 you can modify the correlation
between the direction on the lever and the direction on the actuator. The following examples show how to
operate in case there is not the exact correspondence between the command lever and the actuator.
System with mechanical throttle and mechanical gearbox
Problem Solution
The gearbox push-pull
cable positions are inverted
while the throttle push-pull
cable works correctly
(forward and backward
positions are inverted)
Set A0=3
The gearbox is working
correctly while the throttle
push-pull cable positions
are inverted (min and max
throttle positions are
inverted)
Set A0=1
Both gear or throttle push-
pull cables positions are
inverted
Set A0=2
13.3. Specific parameters
Display
code
Description Values
Factory
value
Value shown on
display (factory value)
Note
A0
Push-pull cable movement
direction
1 .. 4 4 4
dI
Delay before disengaging
the gearbox
0 .. 9,9 s 0,0 s 0
dA Delay on the throttle 0 .. 9,9 s 0,0 s 0
PP Proportional coefficient 0 .. 99 40 40
PI Integral coefficient 0 .. 99 0 00
These parameters
must not be
changed
CC To be used for the check-up of the internal CANBus communication
OL
OF
OH
Gearbox
UL
UH
Throttle
