Flexball Italiana S.r.l. 6
3.1. Control keypad
On the command station it is mounted an electronic keypad with 4 push-buttons and 4 LEDs.
(*) In installations with single engine, both the green LEDs are referring to the same engine. In systems with 2
engines the push button and the green LED on the right are referring to the starboard engine while the push
button and the green LED on the left side are referring to the port engine.
Description LEDs colour
Engine (*) Green
Warm/Sync Orange
Command Red
Engine (*) Green
Command station series 3500
Command station series 4500
