21.5. LED diagnosis on command station
Command station produces signals to show either the operating conditions or possible causes of irregularities.
LED indications
When it
happens
Meaning/problem What to do
1° flash long and 2° flash long
Command station configured
for installations with 1 motor
1° flash short and 2° flash long
Command station configured
for installations with 2 motors
and 1 actuator
1° flash short and 2° flash short
Power up
Command station configured
for installations with 2 motors
and 2 actuators
If you need to reconfigure
the command station see
section 4.3
2 LED green with fixed light
Gearbox command is in
neutral, the installation works
correctly
-
On the command station don’t
light on either 1 or 2 green LED
• Power supply is missing
• In installation with push-
pull cables, the gearbox
hasn’t come to neutral
position
• Check on the actuator
that the display is
enlightened
• Check and remove the
obstacle which don’t let
the actuator go to
neutral position (see
sections 3.6. and 21.3.)
Green LED on command
stations is blinking (90% ON,
10% OFF)
Command station is not
configured correctly wilt
respect to the type of
installation; command station
has been configured for
installations with 1 actuator
and it must be configured for
installations with 2 actuators
Reconfigure command
station as described at
section 4.3.
Green LED on command station
is blinking (50% ON, 50% OFF)
Might be a problem on the
positioning measuring device
of the command station
Contact Flexball
All 4 LEDs are blinking
After power
up
There is a failure on
mechanical actuators,
probably due to an extra load
on push-pull cables
To remove the falure refers
at section 21.3.
