17. Programming of actuators with electronic CANBUS motor and
mechanical gearbox
17.1. Installation of the push-pull cable and programming of the cable stroke
Please refer to sections 9., 12. and 13.2.
17.2. Specific parameters
Display
code
Description Values
Factory
value
Value shown on
display (factory value)
Note
dI
Delay in switching off the
gearbox
0 .. 9,9 s 0,0 s 00
dA Delay in start of throttle 0 .. 9,9 s 0,0 s 00
dF
Delay in neutral; it occurs
any time you move directly
from forward to reverse or
from reverse to forward.
This delay does not occur
when from neutral you
move to forward or reverse.
0 .. 9,9 s 0,5 s 05
CP Canbus protocol 1-99 0 00
See 17.2.2.
CC CANBus communication - - -
17.2.1. CANBus protocol
Every CANBus interface card has one output. Communication starts automatically at power-up.
This document refers to SAE J1939 CANBus protocol. The electronic system can handle also other
communication protocols.
Bit rate Repetition rate Identifier
29 bit in according to CAN 2.0B
default value default value description n° byte
250 Kbit/s 10 ms Priority 1
PGN 2
Address 1
Identifier:
Identifier Priority PGN Address
Hexadecimal values (_)
0x_ _ 0x_ _ _ _ 0x_ _
