5 – X-series Camera Controller
X-series User’s Manual 35
X6800/X6900 Frame Size Variables
Minimum
Maximum
Step Size
Frame Width
32
640
32 pixels
Frame Height
4
512
4 pixels
Horizontal Offset
0
Depends on
window size
4 pixels
Vertical Offset
0
Depends on
window size
4 pixels
X8500 Frame Size Variables
Minimum
Maximum
Step Size
Frame Width
64
1280
32 pixels
Frame Height
4
1024
4 pixels
Horizontal Offset
0
Depends on
window size
4 pixels
Vertical Offset
0
Depends on
window size
4 pixels
NOTE: Windowing in the horizontal direction will not affect frame rate.
5.4.2.2.2 Analog Video sub-tab
The analog video outputs always put out a standard size video frame. If the camera FPA image is
windowed down in size, then there will be black areas in the Analog Video. The Analog Video sub tab
allows the user to control how the FPA digital image data is positioned within the analog video frame.
