5 – X-series Camera Controller
X-series User’s Manual 18
5.1 Online Help
The X-Series Camera Controller provides two online help options. First there is this manual which
can be accessed via the Help menu. Second, when placing the mouse cursor over a particular
control, a Tooltip will be displayed giving a basic description of the control.
5.2 Menu Bar
The menu bar is the same for both Basic and Advanced User Modes.
Save State (name)
Saves the camera state to the current (name).
This state will be reloaded at power up. Stored in
flash memory.
Save State As
Saves the current camera state to a name chosen
by the user. State names other than (name) may
be loaded manually. Stored in flash memory
Load State
Load a state from flash memory.
Manage States
Rename or delete states from camera memory.
Load Factory
Defaults
Loads factory defaults for all camera Settings and
NUCs. The factory defaults cannot be modified
by the user.
NOTE: Camera states contain information about all configurable camera parameters. They do not
contain the NUC data, but they do contain the filenames of the currently loaded NUCs. These NUCs
will be reloaded with the state; however, if the NUCs are changed, deleted, or renamed, the state may
not be able to load the NUCs.
5.2.1 Tools Menu
NEOS Lens Control
Activates control link to certain
motorized lenses
Filter Info
Shows ID info for filters in wheel
Set Time
Options for setting time
User Mode
Select Basic or Advanced mode
Set PC Time to
Sets the PC clock to the time from the
