6.2.10 Auxiliary Connector/Breakout Cable
This connector provides access to a number of less commonly used input and output signals. The
inputs and outputs are easily accessed using the Aux Breakout Cable (P/N 4212860) supplied with
the camera. The camera auxiliary connector is a standard DB-26 (mating connector: Digikey PN
A31505-ND).
Pin
Signal
Level
Cable Molded-In Label
Connector Type
2
TX
RS-232
Serial
DB9 Female connector
4
RX
RS-232
5
GND
10
INTEG ACTIVE
TTL
10
BNC Male
11
GND
14
Reserved
14
BNC Male
15
DIG_IN0
3V/5V CMOS
15
BNC Male
16
Reserved
16
BNC Male
17
DIG_IN1
3V/5V CMOS
17
BNC Male
18
Reserved
18
BNC Male
19
DIG_IN2
3V/5V CMOS
19
BNC Male
20
Reserved
20
BNC Male
21
TRIG_IN
3V/5V CMOS
21
BNC Male
22
GND
23
ANALOG_IN0
0-5V
23
BNC Male
24
ANALOG_IN1
0-5V
24
BNC Male
25
LOCKIN
0-5V
25
BNC Male
26
GND
Here is an image of the breakout cable, and a closeup of the molded-in number on Cable 20, which is
reserved for future capabilities:
