FLIR X-Series User Manual

8 – Specifications
X-series User’s Manual 88
Update Offset (recalculates offset using current gain, volatile)
NUC Source
Internal: TE controlled flag
External: Any user supplied source which covers entire window
Bad Pixel Replacement
Two-Point Gradient, or nearest neighbor
Number of NUC’s
4 active NUC’s in preset selectable form
Greater than 24 full frame NUC’s saved in camera memory
NUC Time
< 5 seconds
NUC Performance
Residual Non-Uniformity: 0.1%
8.7 Detector/FPA
Spectral Response
Xxx00sc/xx02: 1.5-5um; Xxx01/xx03: 3-5um
Detector Type
InSb or Type 2 SLS
Detector f/#
f/2.5 or f/4
Supported ROIC
X6800/X6900: ISC0804
X8500: ISC1308
Integration Mode
Snapshot
Format (HxV)
X6800/X6900: 640x512
X8500: 1280x1024
Operability
>99.5%, 99.9% typical
Charge Handling
Capacity
X6800/X6900: 11.0 x 10
6
carriers
X8500 (InSb) : Gain 0: 3.0 x 10
6
carriers
X8500 (SLS) : Gain 1: 11.5 x 10
6
carrier
Detector Pitch
X6800/X6900: 25 microns
X8500: 12 microns
Detector Cooling
Linear Sterling Cooler
8.8 General Characteristics
Size
Length
Width
Height
249 mm (9.8 inches), not including lens or lens cover
156 mm (6.2 inches)
201 mm (7.9 inches) w/ handle, 147 mm (5.8 inches) w/o handle
Weight
6.4 kg (14 lbs.), not including lens or lens cover
Temperature
