FLIR X-Series User Manual

8 – Specifications
X-series User’s Manual 84
8.3 Acquisition Modes and Features
Frame Rate (X6800):
Max at Full Window
Max at Minimum Window
Minimum
Resolution
520.91 Hz (< 1.906mS Integration Width)
23076.92 Hz (<30uS Integration Width)
1.45mHz
90nS
Frame Rate (X6900):
Max at Full Window
Max at Minimum Window
Minimum
Resolution
1004 Hz ( < 0.996mS Integration Width)
29113 Hz ( < 34.3uS Integration Width)
1.45mHz
90nS
Frame Rate (X8500):
Max at Full Window
Max at Minimum Window
Minimum
Resolution
181 Hz ( < 5.52mS Integration Width)
6026 Hz ( < 166uS Integration Width)
1.45mHz
90nS
Pixel Rate (burst)
355 MHz
Integration Width
Maximum
Minimum
Resolution
>98% selected frame time (1/frame rate)
270 nanoseconds
90 nanoseconds
Synchronization Modes
• Genlock: synchronizes composite video to external
composite video source or HDMI/SDI to external SDI or
“Y” signal from component signal (Not available in
X6800)
• Frame Sync Starts Integration: synchronizes FPA
integration to external sync source
• Frame Sync Starts Readout: synchronizes FPA data
readout to external sync source
Preset Sequencing
• 4 presets programmable for 1 to 4,294,967,295 frames
each
• Preset sequence programmable for up to 4,294,967,295
sequences per triggered event
Digital Video Output
Selectable:
