6.2 Electrical – X8500 and X6900 Series
The X8500 and X6900-Series cameras interface to the host computer through a variety of industry
standards and camera specific signals. All pinouts and connectors are commercial standard types. All
connections are on the back panel of the camera, as shown below. The last digit of the following
section numbers corresponds to the callout numbers on the picture below.
6.2.1 Power Switch
Illuminates when camera power is ON. Switch is mechanical and
retains its ON/OFF statues through a power cycle. Camera power
cannot be controlled remotely.
