FLIR X-Series User Manual

5 – X-series Camera Controller
X-series User’s Manual 39
When a trigger occurs, the camera will complete a sequence a set number of times. For example, if
Preset Sequencing is used with a dwell of two frames set for all four presets, each trigger would
generate 8 frames. If the user set the camera to complete 3 sequences upon triggering, the camera
would generate 24 frames.
Trigger Modes
Free Run
In free run the camera cycles through frames/sequences
continuously.
Trigger, then do this
many sequences
Upon receiving a trigger (external or software), the camera
generates the number of sequences entered in the box (max
limit: >4x10
9
).
Trigger then free run
Upon receiving a trigger (external or software) the camera will
start to generate sequences continuously.
External Preset
Advance
Upon receiving a trigger (external or software) the camera will
advance to the next preset with a non-zero dwell setting.
Preset 0 Preset 1 Preset 2 Preset 3
Trigger
Preset 0 Preset 1 Preset 2 Preset 3 Preset 0 Preset 1 Preset 2 Preset 3
Sequence Sequence Sequence
nSequences = 3
ITR Frame Process
5.4.2.3.2 Sync Source
The Source options page allows the user to select the source for Syncs and Triggers.
