5 – X-series Camera Controller
X-series User’s Manual
58
Turns the overlay On or Off without changing the selected options
Displays the system date stamp
Displays the system time stamp
Displays the accumulated camera “on” time (H:M). (Cannot be reset by
user)
Display the level of Digital Zoom (x1, x2, x4), and position (C, F, O)
Displays the temperature of front panel sensor in °C
Displays the current temperature of air gap between front panel and internal
chassis in °C
Displays the current temperature of the internal chassis in °C
Displays the ROI used to compute AGC values. Option is disabled if AGC
ROI not enabled.
Displays the NUC flag status
Displays the current analog video palette name
Displays camera model and serial number
Displays current IRIG time
