Page 49CWT Compact S4 Touch Installation & Maintenance Manual for CWT 1.0-0Issue 3
Product description
Connector
Com port
Type/Outlet name
Function
F2
10A Fuse ATO
J1
USB0A
USB 2.0 Host Type A
J2
Speaker
J3
Expansion board
J4
Not mounted
J5
Ethernet
J6
USB1
USB 2.0 host type A
J7
12Vprinter
12V Printer from Battery
J8
Com 7
External SPI UART
Serial 2
J9
Com 2
CWT Cap Bus
J10
IN#1
Opto coupled input. E.g. Seismic alarm
J11
Zl-Air Battery
Extra battery Zink-Air
J12
RELAY
Relay Output
J13
Com 9
Internal iMX53 UART
Serial 4 (5V_COM_9)
J14
Bat. IN
Battery 12 V In
J15
24Vprinter
24V Printer
J16
CWT-CAP BUS
CWT Cap Bus
J17
Not mounted
J18
Coin-Box
Coin Box pin 1 and 2
Lower Door pin 3 and 4
J19
12 V to External Pay Unit (12V_1)
J20
Door-SW
Upper Door switches
J21
Not mounted
J22
Com 8
External SPI UART
Printer - Serial 3 (5V_COM_8)
J23
Status LEDs &
Ambient light
Status LEDS and Ambient light sensor
J24
Com 1
External SPI UART
Touch controller - Serial 5 (5V_COM_1)
J25
AVR JTAG for loading of AVR software
