Page 50CWT Compact S4 Touch Installation & Maintenance Manual for CWT 1.0-0Issue 3
Product description
Connector
Com port
Type/Outlet name
Function
J26
USB0B
USB Device type B
J27
SolarPanel36cell
Solar Panel 36 cells Input
J28
STN-LCD
STN Display
J29
12 V Out from Battery (12V_2)
J30
debug
Debug port
J31
Com 4 (**
Internal iMX53 UART
Expansion board (5V_COM_4)
J32
Wake up button
J33
SD Card
J34
External Light
J35
Com 3 (*
Internal iMX53 UART
External pay unit or bill reader - Serial 1
(5V_COM_3)
J36
SolaPanel
Solar Panel
J37
Com 3 (*
Internal iMX53 UART
MDB
External pay unit or bill reader - MDB
(12V_MDB)
J38
Boot Mode
Boot Mode
J39
Fuse Volt
Fuse Voltage
J40
Not mounted
J41
Colour Display
Colour display with LDVS and Backlight
J42
12 V Printer
J44
Not mounted
J45
Microphone
J47
JTAG imx53
J48
Not mounted
J49
Not mounted
SW8
OFF ON
On/Off Switch
U49
WGSM
Modem Antenna
U57
SIM Card
