Juno System: User Guide
Appendix D: Safety
Symbols on the Instrument
60
CAUTION PINCH HAZARD. The instrument door and tray can pinch your hand.
Make sure your fingers, hands, and shirtsleeves are clear of the door and tray when
loading or ejecting an integrated fluidic circuit (IFC).
Symbols on the Instrument
The following table describes the hazard symbols that may be used in this document or on
labels on the instrument.
Electrical Safety
NOTE The main power disconnect is on the rear panel of the instrument.
WARNING ELECTRICAL HAZARD. DO NOT REMOVE THE COVERS. Electrical
shock can result if the instrument is operated without its protective covers. No
internal components are serviceable by the user.
Symbol Description
Hazard. Consult the user guide for further information.
Hot surface hazard. Do not touch; potential for personal injury.
Biohazard.
Electricity hazard. Indicates high electricity levels and a threat of electric shock from
machines and/or equipment in the vicinity. You may suffer severe injuries or death.
Pinch hazard. Indicates where pinch hazards exist. Exercise caution when operating
around these areas.
Lifting hazard.
Power switch is in the Off position.
Power switch is in the On position.
Protective conductor terminal (main ground). It must be connected to earth ground before
any other electrical connections are made to the instrument.
To minimize negative environmental impact from disposal of electronic waste, do not
dispose of electronic waste in unsorted municipal waste.
Follow local municipal waste ordinances for proper disposal provision. Contact customer
service for information about responsible disposal options.
