Juno System: User Guide
Chapter 1: Introducing the Juno System
Components of the Juno System
8
Components of the Juno System
Figure 1. Front panel of the Juno instrument.
Figure 2. Back panel of the Juno instrument. There are also two USB 2.0 ports on the side of the
instrument.
Touchscreen
interface
Retracted tray
Power and
standby indicator
USB 2.0 ports
Ethernet
port
DVI port
ON/OFF switch
Power socket
Compressed
air input
Exhaust fan
