Juno System: User Guide
Chapter 1: Introducing the Juno System
Components of the Juno System
9
Figure 3. Tray and thermal chuck of the Juno instrument. The white notch is used to orient the notched
corner of the IFC in the tray.
Figure 4. Interface Plate Loading Fixture
White notch
