INTRODUCTION AND SPECIFICATIONS
Table 1-3. 6080A/AN Specifications (cont)
IEEE-488
INTERFACE FUNCTIONS SH1, AH1, T5, TE0, L3, LEO, SR1, RL1, PRO,
DC1, DT1, C0, and E2. Complies with IEEE Std.
488.1-1987 and 488.2-1987.
INTERNAL MODULATION SOURCE
SINE WAVE 10 Hz to 100 kHz synthesized sine wave.
DISPLAY RANGES 00.1 to 99.9 Hz
100 to 999 Hz
1.00
to
9.99
kHz
10.0
to
99.9
kHz
100 to 200 kHz
FREQUENCY RESOLUTION 0.1 Hz or 3 digits
OUTPUT LEVEL RANGE 0 to 1V RMS into 600 ohms
DISTORTION < 2% THD
OUTPUT IMPEDANCE 600 ohms ±10%
EXTERNAL MODULATION
1V peak provides indicated modulation index.
Nominal input impedance is 600 ohms. Maximum input level is ± 5 V peak.
MODULATION MODES
Any combination of AM, PULSE, and FM, internal or external, may be used.
GENERAL
TEMPERATURE
Operating 0 to +50°C (+32 to +122°F).
Non-Operating -40 to +75°C (-40 to +167°F).
HUMIDITY RANGE
Operating 95% to +30°C, 75% to +40°C, and 45% to +50°C.
ALTITUDE
Operating Up to 10,000ft.
VIBRATION
Non-Operating 5 to 15 Hz at 0.06 inch, 15 to 25 Hz at 0.04 inch,
and 25 to 55 Hz at 0.02 inch, double amplitude (DA).
SHOCK
Non-Operating MIL T 28800D Class 5, Style E.
1-7
