INTRODUCTION AND SPECIFICATIONS
Table 1-3. 6080A/AN Specifications (cont)
ELECTROMAGNETIC COMPATIBILITY.. The radiated emissions induce < 1 μV into a 1-inch
diameter, 2-turn loop, 1-inch from any surface as
measured into a 50-ohm receiver.
COMPLIES WITH THE FOLLOWING STANDARDS:
CE03 of MIL-STD-461B (Power and interconnecting leads), 0.015 to 50 MHz.
RE02 of MIL-STD-461B (14 kHz to 10 GHz).
FCC Part 15 (J), class A.
CISPR 11.
SIZE Width Height Depth
43 cm
13.3
cm
59.7
cm
17 in
5.25
in
23.5
in
POWER 115/230 VAC, ± 10% 50, 60, and 400 Hz ±10%
250 VA maximum
WEIGHT < 27 kg (60 Ibs).
1-8
