INTRODUCTION AND SPECIFICATIONS
Table 1-4. Typical Signal Generator Performance
FREQUENCY (10-DIGIT DISPLAY)
RANGE
BAND .01-15 MHz
BAND 15-32 MHz ..............................
BAND 32-64 MHz
BAND 64-128 MHz
BAND 128-256 MHz
BAND 256-512 MHz
BAND 512-1056 MHz
RESOLUTION
ACCURACY
REFERENCE (Internal)
REFERENCE (External)
Choice is internal swit
AMPLITUDE (3 1/2-DIGIT DISPLAY)
RANGE
RESOLUTION
ACCURACY
(+23 ± 50°C)
ACCURACY
(0 to +50°C)
0.01 to 1056 MHz in 7 bands:
0.01 to 14.999999 MHz,
15 to 31.999999 MHz,
32 to 63.999999 MHz,
64 to 127.999999 MHz,
128 to 255.999999 MHz,
256 to 511.999999 MHz,
512 to 1056 MHz.
1 Hz
Same as reference (See REFERENCE).
The unit operates on an internal 10 MHz TCXO. The
Frequency variation will be < 2 ppm peak to peak
over the temperature range of 0 to +50°C. Aging rate
of <± 1 ppm/year typical.
Internal reference signal (10 MHz) available at rear
panel REF OUT connector, level > 0 dBm, terminated
in 50 ohms.
Frequency stability after 2 hour warmup is < ± 0.05
ppm/hour at +25°C ± 5°C.
Accepts (1, 2, or 5) or 10 MHz signal. Level required
is 0.2 to 2.0 Vrms into 50-ohms termination.
NOTE
ch selectable (1, 2, or 5 MHz).
+19 to -140 dBm for Frequency < 512 MHz.
+16 to -140 dBm for Frequency > 512 MHz.
0.1 dB (< 1% or 1 nV in volts). Annunciators for dB,
dBm, dBf, V, mV, μV, dB mV, dB μV, and EMF.
± 1 dB from +19 to -127 dBm and for F from 0.4 to
512 MHz.
± 1 dB from +16 to -127 dBm and for F > 512 MHz.
± 1.5 dB from +19 to -127 dBm and for from 0.4 to
512 MHz.
± 1.5 dB from +16 to -127 dBm and for F > 512 MHz.
1-9
