Fluke 724 Calibration Manual

724/725/726
Calibration Manual
10
RTD Accuracy (Read and Source) (ITS-90) (726)
Range Minimum Maximum Accuracy
Ni120 (672) -80.00 260.00 0.15
-200.00 100.00 0.15
100.00 300.00 0.25
300.00 600.00 0.35
Pt100 (385)
600.00 800.00 0.45
-200.00 100.00 0.15
100.00 300.00 0.25
Pt100 (3926)
300.00 630.00 0.35
-200.00 100.00 0.15
100.00 300.00 0.25
Pt100 (3916)
300.00 630.00 0.35
-200.00 100.00 0.75
100.00 300.00 0.85
Pt200 (385)
300.00 630.00 0.95
-200.00 100.00 0.35
100.00 300.00 0.45
Pt500 (385)
300.00 630.00 0.55
-200.00 100.00 0.15
100.00 300.00 0.25
Pt1000 (385)
300.00 630.00 0.35
CU10 -10.00 250.00 1.8
Notes: Read Accuracy is based on 4-wire input. For 3-wire input, add ± 0.05 Ω assuming all three RTD
leads are matched.
Source Accuracy is based on 0.5 to 3.0 mA excitation current (0.1 mA for pt1000 range)
Resolution: 0.1 °C, 0.1 °F
Allowable excitation current (source): Ni120, Pt100-385, Pt100-392, Pt100-JIS,
Pt200-385: .05 to .80 mA,Pt500-385: 0.05 to 0.80 mA; Pt1000-385: 0.05 to 0.40 mA
RTD Source: Addresses pulsed transmitters and PLCs with pulses as short as 5 ms. SN < 7624001 may
need modification for pulses less than 15 ms.

Fluke 724 Specifications

General

Temperature Range	-10°C to 55°C
Thermocouple Types	J, K, T, E, R, S, B, L, U, N
Current Measurement	0 to 24 mA
Operating Temperature	-10°C to 55°C
Function	Process calibrator
RTD Types	Pt100, Pt500, Pt1000
Voltage Measurement	0 to 10 V
Loop Power	24 V DC
Display	Dual Display
Power Supply	4 AA batteries
Resolution	0.1 °C
Storage Temperature	-20 °C to 60 °C
Battery Life	25 hours
Relative Humidity	0 % to 90 %
Safety Compliance	CSA C22.2 No. 1010.1:1992
