Fluke 724 Calibration Manual

Calibrators
Replaceable Parts
67
Replaceable Parts
When servicing this Calibrator, use only the replacement parts specified. User-
replaceable parts are listed in Table 19 and shown in Figure 36.
Table 19. Replacement Parts
Item Description Fluke No. Quantity
A
724-725 Case top
726 Case top
664232
2491880
1
B
724 LCD mask
725 LCD mask
726 LCD mask
1548383
664273
2491914
1
C
Elastomeric strips 802063 2
D
724 Input/output bracket
725 - 726 Input/output bracket
1549921
691391
1
E
LCD bracket 658390 1
F
Mounting screws 494641 11
G
Backlight 690336 1
H
724 - 725 LCD 690963 1
I
724 Keypad
725 Keypad
726 Keypad
1548126
690955
2461532
1
J
Case bottom 664235 1
K
AA alkaline batteries 376756 4
L
Case screws 832246 4
M
Battery door 664250 1
N
Accessory mount 658424 1
O
Tilt stand 659026 1
P
Battery door 1/4-turn fasteners 948609 2
Q
TL75 series test leads 855742 1
R
Test lead, red
Test lead, black
688051
688066
1
1
S
AC70A alligator clip, red
AC70A alligator clip, black
738047
738120
1
1
T
724 Case top decal
725 Case top decal
726 Case top decal
1548329
690948
2530988
1

Fluke 724 Specifications

General

Temperature Range	-10°C to 55°C
Thermocouple Types	J, K, T, E, R, S, B, L, U, N
Current Measurement	0 to 24 mA
Operating Temperature	-10°C to 55°C
Function	Process calibrator
RTD Types	Pt100, Pt500, Pt1000
Voltage Measurement	0 to 10 V
Loop Power	24 V DC
Display	Dual Display
Power Supply	4 AA batteries
Resolution	0.1 °C
Storage Temperature	-20 °C to 60 °C
Battery Life	25 hours
Relative Humidity	0 % to 90 %
Safety Compliance	CSA C22.2 No. 1010.1:1992
