Fluke 724 Calibration Manual

Calibrators
Performance Tests
35
Lower Display Thermocouple Source Test
1. Set the 5520A to measure Type-J thermocouple voltages.
2. Press M on the UUT until SOURCE appears on the lower display. If necessary,
press T on the UUT until J appears on the lower display and press D (use the
configuration menu on the 726) so the temperature is displayed in °C.
3. Use the arrow keys to set the UUT outputs to the temperatures in Table 14 and verify
that the 5520A temperature readings are within the limits shown.
4. Press STBY on the 5520A. Remove the TC lead from the 5520A and the UUT.
Table 14. Lower Display Thermocouple Source Readings
UUT Settings
724/725
5520A Readings
726
Readings
(referenced to 0 °C)
0.0 °C -0.7 °C to +0.7 °C -0.4 °C to +0.4 °C

Fluke 724 Specifications

General

Temperature Range	-10°C to 55°C
Thermocouple Types	J, K, T, E, R, S, B, L, U, N
Current Measurement	0 to 24 mA
Operating Temperature	-10°C to 55°C
Function	Process calibrator
RTD Types	Pt100, Pt500, Pt1000
Voltage Measurement	0 to 10 V
Loop Power	24 V DC
Display	Dual Display
Power Supply	4 AA batteries
Resolution	0.1 °C
Storage Temperature	-20 °C to 60 °C
Battery Life	25 hours
Relative Humidity	0 % to 90 %
Safety Compliance	CSA C22.2 No. 1010.1:1992
