EtherScope™ Series II
Getting Started Guide
86
Viewing AutoTest Results
After you power on the instrument, it runs the
automated tests and displays the Test Results screen, as
shown in Figure 24.
Figure 24. Wireless LAN Test Results Screen
The Test Results screen gives you at-a-glance visibility
into the state of your WLAN.
The main pane displays the name of each test and
reports its status. The icons along the right side give you
a visual indication of the progress and status of each test:
•
Running
• Not running
•
Completed and passed
•
Completed and failed
The preview pane provides a summary of the results of
the test that is selected in the main pane.
Note
When autotest finishes, the Connection test (the
default selection) is highlighted.
