Fronius Symo Service Manual

99
EN
Service codes
Safety
General These service codes help to localise and - where possible - rectify faults with the device
directly on site. The individual service codes are subdivided into service classes.
The following information is given for every service code:
- the reason the service code is being displayed
- the relevant troubleshooting measure
Displaying status
codes
The inverter performs a system self diagnosis that automatically detects many faults that
may occur and shows them on the display. This means you are promptly made aware of
malfunctions in the inverter and the photovoltaic system, or of any installation or operating
faults.
If the system self diagnosis has detected a specific fault, the associated status code will be
shown on the display.
Software update
after a PC board
replacement
In rare cases, an incompatibility message „State 480“ may occur on the inverter after the
PC board has been successfully replaced.
Please carry out a software update or contact Fronius Technical Support National.
Total failure of the
display
If the display fails to come on some time after sunrise:
- Check the AC voltage ON the inverter connections:
the AC voltage must be 230 V (+ 10 % / - 5 %)*
- Carrying out an AC reset: Disconnect the inverter when not under load from the AC
supply and switch it back on
* The mains voltage tolerance depends on the country setup
WARNING! An electric shock can be fatal. Before opening the device:
- If applicable, turn the mains switch to the -O- position
- Unplug the device from the mains
- Disconnect the inverter from the DC side
- Using a suitable measuring instrument, ensure that electrically charged parts
(e.g. capacitors) are fully discharged
- Restrict access to the working area
- Take steps to ensure the metallic surfaces of the device cannot be touched
- Suitable protective clothing and equipment must be worn when carrying out
the test or the repair
IMPORTANT! Software may only be updated after consulting the Solar Electronics hotline.
The need for the update will be clarified in advance depending on the serial number and
firmware version.
IMPORTANT! Status codes may sometimes appear briefly as a result of the inverter's con-
trol response. If the inverter then continues working with no sign of any problem, this
means that there was no fault.

Fronius Symo Specifications

General

THD	< 3 %
Number of MPP Trackers	2
Protection Class	IP65
Frequency Range	50 / 60 Hz
Operating Temperature Range	-25°C to +60°C
Power Range	3.0 kW - 20.0 kW
AC Output Voltage	230 V
Communication	Ethernet
Warranty	5 years
Model	Symo
