10
Fit the gas nozzle back onto the welding torch
Measuring the
welding circuit
resistance (stick
welding)
NOTE!
Risk of incorrect measurement of the welding circuit resistance.
This can have a negative effect on the welding results.
▶
Ensure that the workpiece has an optimum contact surface in the area of the earth-
ing clamp (clean surface, no rust, etc.).
1
Ensure that the STICK welding process is selected
2
Establish a ground earth connection to the workpiece
3
Access the Setup menu 2nd level (2nd)
4
Select parameter "r"
NOTE!
Risk of incorrect measurement of the welding circuit resistance.
This can have a negative effect on the welding results.
▶
Ensure that the workpiece has an optimum contact surface for the electrode flush
(clean surface, no rust, etc.).
5
Place the electrode flush against the workpiece surface
6
Press the "Parameter selection" button (right)
- The welding circuit resistance is calculated. "run" is shown on the display during
the measurement
The measurement is finished when the welding circuit resistance is shown on the display
in mOhm (for example 11.4).
