6.5 List of parameter
Basic parameter
The basic parameters are rather frequently adjusted. Changing almost any basic parameter immediately affects the amplifier and the motor
actions.
■ Basic parameter for RYS-V type (1/2)
Para. Name Setting range Initial value Change
01 Manual feed speed 1 0.01 to Max. speed [r/min] (in 0.01 steps) 100.00 Always
02 Manual feed speed 2 0.01 to Max. speed [r/min.] (in 0.01 steps) 500.00 Always
03 Manual feed speed 3 0.01 to Max. speed [r/min.] (in 0.01 steps) 1000.00 Always
04 Manual feed speed 4 0.01 to Max. speed [r/min.] (in 0.01 steps) 100.00 Always
05 Manual feed speed 5 0.01 to Max. speed [r/min.] (in 0.01 steps) 100.00 Always
06 Manual feed speed 6 0.01 to Max. speed [r/min.] (in 0.01 steps) 100.00 Always
07 Manual feed speed 7 0.01 to Max. speed [r/min.] (in 0.01 steps) 100.00 Always
08
to
15
Unused 0 −
16 Maximum speed 0.01 to Max. speed [r/min.] (in 0.01 steps) 5000.00 Always
17 Override 1 0 to 150% (in 1% steps) 10 Always
18 Override 2 0 to 150% (in 1% steps) 20 Always
19 Override 4 0 to 150% (in 1% steps) 40 Always
20 Override 8 0 to 150% (in 1% steps) 80 Always
21 Acceleration time 1 0.000 to 99.999s (in 0.001s steps) 0.100 Always
22 Deceleration time 1 0.000 to 99.999s (in 0.001s steps) 0.100 Always
23 Acceleration time 2 0.000 to 99.999s (in 0.001s steps) 0.500 Always
24 Deceleration time 2 0.000 to 99.999s (in 0.001s steps) 0.500 Always
25 Non-linear (Scurve) filter coefficient 0.000 to 99.999s (in 0.001s steps) 0.000 Always
26
to
30
Unused −−−
31 Tuning method 0: Manual 1: Auto(Low stiffness) 2: Auto (High stiffness) 1 Always
32 Load inertia ratio 0.0 to 100. 0 times (in 0.1 steps) 0.0 Always
33 Operation speed response 10 to 1000Hz (in 1Hz steps) 100 Always
34 Speed response at stoppage 10 to 1000Hz (in 1Hz steps) 100 Always
35 Stop detection width 5 to 100 [r/min] (in 1 steps) 20 Always
36 Stop judgment time 0.00 to 1.00s (in 0.01s steps) 0.00 Always
37 Torque filter time constant 0.00 to 20.00 [ms] (in 0.01ms steps) 0.30 Always
38 Speed regulator integration time 1 to 1000 [ms] (in 1 steps) 20 Always
39 Position regulator gain 1 to 1000 (in 1 steps) 50 Always
40 Feed forward gain 0.000 to 1.5000 (in 0.001 steps) 0.000 Always
41 Speed setting filter 0.0 to 20. 0 [ms] (in 0.1 steps) 0.0 Always
42 Speed feedback filter 0: OFF 1: ON 0 Always
43 Torque setting filter 0.0 to 9.9s (in 0.1 steps) 0.1 Always
44 Vibration suppression time constant 10 to 1000 [ms] (in 1 steps) 100 Always
45 Vibration suppression gain 0.00 to 1.00 (in 0.01 steps) 0.00 Always
46
to
50
Unused −−−
