Connecting external devices
A26391-K124-Z100-1-7619 69
Ê Place your workstation on the docking device and push it evenly in the direction of the arrows
until you feel it engage.
Docking switched-off workstation
!
The power adapter cable may not be connected to the DC socket (DC IN) of the
workstation when you dock the workstation.
Ê Put your docking device into operation (see documentation for the docking devices).
Ê Mount the suitable Tray on the docking device.
Ê Switch off the workstation.
Ê Remove all cables connected to workstation.
Ê Make sure that the PC card eject buttons of the workstation are pressed in.
Ê Place your workstation on the docking device and push it evenly in the direction of the arrows
until you feel it engage.
Switching on docked workstation
Ê Press the Suspend/Resume button of the workstation.
or
Ê Press the Suspend/Resume button on the left-hand side of the docking device.
Removing workstation
Undocking workstation while running
If an operating system is installed on your workstation that supports "Plug & Play" and "hot docking"
(e.g. Windows 98), you need not switch off the workstation for undocking.
The workstation may also be in an energy-saving mode.
You must prepare the workstation for undocking.
Ê To do this, select Eject PC in the Start menu.
