Working with the workstation
A26391-K124-Z100-1-7619 21
Operating the removable radio keyboard
!
Please take note of the safety information in the "Important notes" chapter.
Removing the radio keyboard
1
1
2
Ê Lift the keyboard at the two positions
indicated (1).
Ê Remove the keyboard in the direction of the
arrow (2).
The keyboard is permanently linked to the
workstation by means of a wireless connection.
The right-hand indicator on the keyboard lights
as soon as a wireless connection is established.
No keyboard input is possible until the indicator
lights. Occasionally it can take up to 15 seconds
to establish a connection (normally 2 to
5 seconds).
i
If you are unable to establish a connection between the keyboard and the CELSIUS
Mobile Workstation, switch the keyboard off and then on again with the ON/OFF switch on
the underside of the keyboard.
