A26391-K124-Z100-1-7619 87
Technical data
Workstation
Processor: Intel Mobile Pentium 4m, 1.7 GHz or higher
Chipset: Intel 845 MP
Socket: µFCPGA2
Main memory: Maximum 1 GB 266 MHz DDR SD RAM
2 slots for 128, 256 and 512 Mbyte modules
JEDEC 200-pin
Possible modules:
• Combo drive (CD-RW/DVD)
• Floppy disk drive LS-240
• Hard disk drive
• Battery
Electrical data
Regulations complied with: EN60950, IEC60950, UL1950, CSA22.2 No.
950, ISO9241, FCC Part 15 Class B
Protection class: III
Maximum power draw:
(workstation on with battery charging)
80 W
LCD display panel
Display diagonal: 15 inch UXGA TFT
LVDS port
Supported screen resolution: max. UXGA, 1600x1200
Graphics
Chip: NVIDIA Quadro 4 500 GO GL
Video memory: 64 MB DDR RAM
Supported resolutions on external monitor:
Colour depth: max. UXGA, 1600x1200
32 bit
Audio
Sound: Intel Sound Max
Modem (Mini PCI modem)
Combo Modem with LAN 56K, V.90 / Ethernet 10/100, PME, AOL 2.0,
WOL
