Fujitsu Primergy RX300 S2 - Page 211

211
PRIMERGY RX300 S2 User’s Guide
Installing Internal Options
7
5 Connect the cable of the parallel port option to the baseboard connector.
6 Attach the top cover.
"7.2 Removing and Attaching the Top Cover" (pg.174)
[Baseboard]
Parallel por
t
connector
[Rear]
