191
PRIMERGY RX300 S2 User’s Guide
Installing Internal Options
7
7.5.2 Installable Expansion Cards and Notes on
Installation
This section explains expansion cards that can be installed on this server and provides notes on
installation.
■ Installable Expansion Cards
● When Installed as Standard
● With Basic Card Slot Conversion Kit
*1: The PG-1862 cannot be installed together with other LAN cards.
■ Location and Order of Expansion Card Installation
For Install expansion cards, use the PCI slots in accordance with the order indicated in the following
table. Install cards in the following order. If they are installed in the wrong order, they will not work
properly.
table: Installable expansion cards (Standard)
Installable card (Model name)
Number of
cards
Remarks
Parallel Port Option (PG-PP03) 1
5
Remote Service Board (PG-RSB103L) 1
SCSI Ctrl U160 lp (PG-130L) 2 Ultra160 SCSI for external SCSI option
Fibre Channel Controller (PG-FC106) 2
Eth. Ctrl 1000-BASE-T Cu lp (PG-1892L) 4
4
1000BASE-T
Eth. Ctrl 1000-BASE-SX Fibre LC lp
(PG-1882L)
2 1000BASE-SX
table: Installable expansion cards (With Basic Card Slot Conversion Kit)
Installable card (Model name)
Number of
cards
Remarks
RAID Ctrl 2-Channel 128 MB w/ BBU
(PG-142E3)
2
3
Ultra320 SCSI 2ch, for external array system,
with battery backup function
Remote Service Board (PG-RSB103) 1
SCSI Ctrl U160 (PG-128) 2 Ultra160 SCSI, for external SCSI option
Fibre Channel Controller (PG-FC106) 2
Eth. Ctrl 1000-BASE-T Cu (PG-1892) 3 1000BASE-T
Eth. Ctrl 1000-BASE-SX Fibre LC
(PG-1882)
2
1000BASE-SX
Eth. Ctrl 1000-BASE-T Cu (PG-1852) 3 1000BASE-T
Eth. Ctrl 2 x 1000-BASE-T Cu (PG-1862)
*1
2
1000BASE-T
To Next Page
