Chapter 7 Installing Internal Options
7.3 Installing a CPU
The server can have up to two CPUs by adding an optional CPU.
7.3.1 CPU Installation Locations
CPU socket 0 is installed with a CPU by default. Install a optional CPU in CPU socket 1.
• Before installation or removal, turn off the server and all peripheral devices.
Also unplug all power cables from the server. "1.4.3 Turning Off the Server"
(pg.33)Failure to do so may cause electric shock or device failures.
• Do not install unauthorized third party CPUs. Doing so may cause failures.
• Do not use CPUs that differ in frequency or cache size. The system will not
start up.
• The circuit boards and soldered parts of internal options are exposed. They
can be damaged by static electricity. Before handling them, first touch a metal
part of the server to discharge static electricity.
• Do not touch the circuitry on boards or soldered parts. Hold the metallic areas
or the edge of the circuit boards.
(Standard)
CPU
Sockets 1
CPU
Sockets 0
Baseboard
[Front]
