Fujitsu Primergy RX300 S2 User Manual

222
Chapter 8 Hardware Configuration/Utilities
8.1 Switch Block Settings
The BIOS password setting can be canceled through the switch block settings.
■ Switch Location
The switch block of the server is located on the baseboard ("1.3.4 Baseboard" (pg.27)) as shown
below.
■ Switch Settings
The following shows the description of each switch.
table: Switch Settings
Switch No. Description
Switch 1 Always keep in OFF position.
Switch 2
Sets whether or not to delete a password.
ON: Deletes the password.
OFF: Does not delete the password. (Default)
Switch 3 Always keep in OFF position.
Switch 4 Always keep in OFF position.
• When setting a switch block, turn off the server and peripheral devices, and
unplug all power plugs from the outlet ("1.4.3 Turning Off the Server"
(pg.33)). Failure to do so may cause electric shock.
ON
OFF
4321

Fujitsu Primergy RX300 S2 Specifications

General

Processor Sockets	2
Chipset	Intel 5000P
Network	2 x Gigabit Ethernet
Form Factor	2U Rackmount
Processor	Intel Xeon 5000/5100/5300 series
Storage	SAS or SATA HDD 2.5"/3.5"
RAID Support	Optional RAID controller
Operating System Support	Windows Server, Linux
Power Supply	Redundant power supply optional
