Chapter1 Overview
1.3.3 Server (Internal)
a Power supply unit
b Memory slot
Contains memory.
c CPU socket
Install the CPU. One socket is installed by default. Up to two sockets can be installed.
d System fan
The system fan has a redundant configuration and a failed system fan can be replaced while the
system is running.
Contact an office listed in the "Contact Information" of the "Start Guide" for the system fan
replacement.
e PCI slot
Contains extension cards that enhance the server functions. Expansion cards with the PCI bus
interface can be installed in the PCI slots.
a
c
b
e
d
