Fujitsu PRIMERGY TX150 S6

100 Options Guide TX150 S6
Cabling Appendix
Figure 84: Cabling - hot-plug PS, 2.5“ hard disks
Cable prefix: T26139-
Power SATA
IDE/FD
ATA 100
Legend:
Data I²C
Slot 3
CPU
iRMC
Battery
Slot 4 Slot 5 Slot 6
LAN
Super I/O
MCH
RAID key
Slot 2 Slot 1
CSS button
Adapter
SAS
USB
<- P9
Tape (middle) Tape (bottom)
PSU E483-V50
<- P1 <- P8
P2 ->
P3 ->
P6 ->
HD 1-4
SAS/SATA Bpl
2.5”
A3C40086493
X6 X1
HD 5-6
SAS/SATA Bpl
2.5”
A3C40086493
X6 X1
Floppy (optional) Optical drive (top)
P5 ->
P4 ->
Y3930-V101
Y2193-V211
