Fujitsu PRIMERGY TX150 S6

TX150 S6 Options Guide 105
Appendix Cabling
Figure 89: Cabling- data, USB, I
2
C, 3.5“ hard disks, 3.5“ hard disks extension box
Cable prefix: T26139-
Power SATA
ATA 100
Legend:
Slot 3
CPU
iRMC
Battery
Slot 4 Slot 5 Slot 6
Super I/O
MCH
RAID key
Slot 2 Slot 1
CSS button
Adapter
SAS
IDE/FD Data I²C
USB
Floppy (optional) Optical drive (top)
IDTemp Combo A3C40078709
Intrusion sw.
Intrusion sw.
System fan
Y3736-V1
Y3718-V508
Y3963-V1
Y3958-V203
Y1248-V8
Y3904-V101
Y2603-V7
SATA RAID controller 2-channel
CH 0
CH 1
Y3963-V201
HD 1-4
SAS/SATA Bpl
3.5”
A3C40070504
X9 X1
X11
HD 5-6
SAS/SATA Bpl
3.5”
A3C40069429
X5 X1
X7
HD extension box
Operating panel A3C40038243
