Installing a LSP ServerView Local Service Panel
Figure 38: Inserting the ServerView Local Service Panel in the multibay
Ê Push the ServerView Local Service Panel from the rear side into the
multibay.
Ê Fasten the ServerView Local Service Panel with two screws on each side to
the multibay.
Figure 39: ServerView Local Service Panel in Multibay
Ê Screw the EasyClick rails onto either side of the multibay using two screws
Ê Push the multibay fully into the bay until the EasyClick rails lock in place.
