Fujitsu PRIMERGY TX150 S6

TX150 S6 Options Guide 53
ServerView Local Service Panel Installing a LSP
Figure 36: ServerView Local Service Panel frame
Figure 37: Inserting the ServerView Local Service Panel in the frame
Ê Push the ServerView Local Service Panel from the front side into the frame.
Ê Detach the EasyClick rails from the multibay by removing the two screws on
each side.
