Fujitsu PRIMERGY TX150 S6 Options Guide

90 Options Guide TX150 S6
Rack model Completion
Ê Push the top cover all the way forward (2).
Ê Fasten the top cover with two screws (3).
If you have not removed the server from the rack cabinet, please skip this page.
V CAUTION!
At least two people are required to install the server in the rack cabinet.
Do not use the handles on the rack front cover to lift the server into the
rack.
Ê Pull the mounted telescopic rails completely out toward the front. They must
click into place so that you can no longer push them back.
Figure 75: Installing the server in a rack cabinet
Ê Lift the server onto the two projecting telescopic rails (1).
V CAUTION!
Never lift or transport the server using the handles on the front panel.
Ê Slide the server a little in the direction marked (2a) until the noses (2b)
engage. When doing this, ensure that the telescopic rails are kept in a locked
position.
3
4a
4b
2b
2a
5
1
