2.2 Connecting the ScanSnap to your PC
ScanSnap S300 Operator's Guide 17
Connecting the ScanSnap
2
When connecting with the USB bus power cable:
Use the USB bus power cable and USB cable .
Operation
1. Connect the USB bus power cable.
Remove the adhesive label covering the USB and Power connectors.
Connect to the ScanSnap's power connector and a personal computer.
2. Connect the USB cable.
Connect the USB cable to both the ScanSnap and personal computer. Insert until it is all the
way seated in the USB connector and USB port.
3. After power and USB connector are connected with cables, perform the procedure
described in "Turning the ScanSnap ON" on page 18.
ATTENTION
• Be sure to use the supplied AC adapter and AC cable.
• Be sure to use the supplied USB cable.
The operation with any commercially available USB cable is not guaranteed.
• If only the USB cable is used, the ScanSnap does not operate. Be sure to use
two types of cables, the power and USB cables, to connect the ScanSnap to a
personal computer.
• Connect the Power cable before connecting the USB cable.
• Be sure to install ScanSnap Manager before connecting the ScanSnap to your
computer. (For how to install them, refer to section "Installing Supplied
Programs" on page 7.)
• When connecting to a USB hub, be sure to use the first stage USB hub that is
closest to the computer. If you use the second or later hub stages, the scanner
may not operate properly.
• When connecting with a USB 2.0 cable, make sure that the USB port to
connect to and hub must be USB 2.0-compliant. Note that if connected with a
USB 1.1 cable, the scanning speed may become slow. When a USB 2.0-
compliant port is available, it is recommended that the USB 2.0-compliant port
be used.
Power
connector
USB
connector
USB port
PC

Fujitsu ScanSnap S300 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
Bundled software	ScanSnap Manager V4.2, ScanSnap Organizer V3.2, CardMinder V3.2
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 95 x 77 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.18 x 3.74 x 3.03 \
Maximum scan area (ADF) (imperial)	8.5 x 14.17 \
Minimum scan area (Auto Document Feeder)	2 x 2 \
Minimum RAM	512 MB
Minimum storage drive space	920 MB
Compatible operating systems	Windows 2000 Professional, Windows XP, Windows Vista
Power supply type	AC/USB
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	1400 g
