Fujitsu ScanSnap S300 User Manual

96
■ Operations in Left-Click Menu Mode
Operation
1. Select [SCAN Button Settings] in the Right-Click Menu, which pops up when the
ScanSnap Manager icon is right-clicked.
⇒ The [Scan and Save Settings] dialog box appears.
2. In the [Application] drop-down list on the [Application] tab, select [Scan2Folder].
3. Click the [OK] button.
⇒ The [ScanSnap Manager -Scan and Save Settings] dialog box closes.
HINT
Changes you have made in the above procedure take effect from the next time
you scan documents using the Left-Click Menu.
For details on how to change settings, refer to section "4.3 Saving Scanning
Settings" (page 70).
S
S

Fujitsu ScanSnap S300 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
Bundled software	ScanSnap Manager V4.2, ScanSnap Organizer V3.2, CardMinder V3.2
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 95 x 77 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.18 x 3.74 x 3.03 \
Maximum scan area (ADF) (imperial)	8.5 x 14.17 \
Minimum scan area (Auto Document Feeder)	2 x 2 \
Minimum RAM	512 MB
Minimum storage drive space	920 MB
Compatible operating systems	Windows 2000 Professional, Windows XP, Windows Vista
Power supply type	AC/USB
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	1400 g
