Fujitsu STYLISTIC Q736 User Manual

Appendix
Installing the Software after the Recovery Image is Restored
Note: The following steps are needed only if you restore the image from the
DVD Recovery Disc S et that yo u pu rchase d.
Installation of essential access software
1. Insert the B ootable Disc in your DVD drive.
2. Open the Drivers folder in the disc, and follow the steps in readme.txt. If there is not a Drive rs
folder in the Bootable Disc, t he computer does not need the essential access software.
The recovery image alrea dy ha s the essential access software installed.
3. You can now connect to the internet and download FSDM (Fujitsu Software Download
Manager) from the support site an d download all the software applicable to the
model and OS using FSDM if they are not downloaded yet.
Auto Installation support for the software downloaded from support website
1. Download FSDM (Fu jitsu Software Download Manager) from the sup- port site and down load all
the drivers applicable to the model and OS using FSDM if they are not downloaded yet.
2. When the software packages are downloaded from the web, it is important to
download the Auto Installer Software package and the m o del/language-specific
Readme file if you prefer to auto install the software.
3. It is important to have the extracted Auto In staller software package folder
and Readme file in the same location as other software folders. Otherwise
autoinstallation of the software will not be supported.
4. Inside th e A uto Installer software package, launch FjAutoinstall.exe as administrator.
5. Click Yes on the User Account Contro l dialog box. This will take some time to
process the software packages. A message will be displayed during this time
stating Please wait while the content is being processed.
6. If the E ULA is displayed for the Fujitsu Software Auto Installer, accept
the EULA, otherwise continue.
7. The Fujitsu Software Auto Installer user interface will be launched providing the ability
to auto install the software dow nloaded from support site.
8. It is recommend ed that you install all the software in the listed order. You can
Select All, to in stall the software in the order listed.
9. Click the Install button t o start the installation.
10. Afte r installing all the selected drivers, the Installati on Results window is d isplayed. Click OK.
11. The You must restart the system for the settin g s to take effect. Do you wish to
reboot now? message appears. Select Ye s.
12. T he syste m will now reboot.
Windows 10 Procedures
It is very important that you create your Recovery Drive befo re beginning to use your system.
It is also important that yo u create a bac kup of the content of the C:\Drivers on your
system to writa ble m edia or an external drive. System-Speci fi c Software Drivers are
also available for down load through the Fujitsu support site.
124 Fujitsu

Fujitsu STYLISTIC Q736 Specifications

General

LED backlight	Yes
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	330 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	QPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2F0
Processor cache	3 MB
Processor cores	2
Processor model	i5-6300U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel® Core™ i5-6300 Mobile Series
Processor threads	4
Processor codename	Skylake
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	42 X 24 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.8 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Internal storage capacity	128 GB
Graphics card	HD Graphics 520
Audio system	Realtek ALC255
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
WWAN	Installed
4G standard	LTE
3G standards	UMTS
SIM card type	MicroSIM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)	867 Mbit/s
Mobile network generation	4G
Microphone in	No
HDMI ports quantity	0
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Cable lock slot type	Kensington
Sustainability certificates	RoHS, ENERGY STAR
Certification	CE, CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL Listed, WEEE
Password protection type	BIOS, Supervisor, User
Platform	Windows
Trial software	McAfee Internet Security and Antivirus Software
Bundled software	Waves MaxxAudio Fujitsu Plugfree Network Fujitsu Anytime USB Charge Utility Fujitsu Battery Utility Fujitsu Function Manager Fujitsu DeskUpdate Microsoft Office
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	9.6 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	88190
Processor socket	LGA 1356 (Socket B2)
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	199.3 mm
Width	309.6 mm
Height	12.7 mm
Weight	990 g
