Technical da ta
Technical data
Tablet PC
General
Processor
6th Generation Intel® Core™ with vPro™
technology (vPro, depending on conguration)
Main memory (SO DIMM) 4 GB / 8 GB DIMM onboard
Electrical data
Safety regulations complied w ith CE, cULus
Protection class III
Maximum power consumption (when the
tablet PC is switched on, connected to the
keyboard docking station and the batte ry is
being charged):
65 W
Touch screen
Size
13.3" Full HD Wide View
Screen resolution 1920 x 1080 / 16 million c olors
Pixel cla ss II
Brightness control 11 levels
Technology Wide-View High-Bright Display with LED
background lighting
Digitizer and glass panel
Dual Digitizer with Anti-Glare Touchscreen
Cameras
Front: H D camera
Back: 5 m e
gapixels, autofocus, mobile light
Graphics card
Chip Intel (c) HD G r aphics 520
Maxim
um re solution of external display:
4096 x 2160
Dime
nsions
Widt
h x Depth x H eight
Standard housing only: 12.56 x 8.19 x 0.5
inches (319 x 208 x 12.7 mm)
Standard housing with keyboard docking
station without battery: 12.56 x 9.76 x 1.17
inches (319 x 248 x 29.6 mm)
Standard housing with power keyboard
docking station with battery: 12.56 x 9.76 x
1.33 inches (319 x 248 x 33.8 mm)
96 Fujitsu

Table of Contents

Other manuals for Fujitsu STYLISTIC Q736

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu STYLISTIC Q736 and is the answer not in the manual?

Fujitsu STYLISTIC Q736 Specifications

General IconGeneral
LED backlightYes
Display diagonal13.3 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display brightness330 cd/m²
Native aspect ratio16:9
Display number of colors16.78 million colors
Bus typeQPI
SteppingD1
Tjunction100 °C
Processor codeSR2F0
Processor cache3 MB
Processor cores2
Processor modeli5-6300U
System bus rate4 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel® Core™ i5-6300 Mobile Series
Processor threads4
Processor codenameSkylake
Processor frequency2.4 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
Processor package size42 X 24 mm
Processor front side bus- MHz
Processor boost frequency3 GHz
Processor operating modes64-bit
PCI Express configurations1x4, 4x1
Supported instruction setsSSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)15 W
Configurable TDP-down frequency0.8 GHz
Internal memory8 GB
Memory clock speed1600 MHz
Internal memory typeLPDDR3-SDRAM
Storage mediaSSD
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Internal storage capacity128 GB
Graphics cardHD Graphics 520
Audio systemRealtek ALC255
Flash typeLED
Rear camera typeSingle camera
Rear camera resolution (numeric)5 MP
Front camera resolution (numeric)2 MP
WWANInstalled
4G standardLTE
3G standardsUMTS
SIM card typeMicroSIM
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.1
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi data rate (max)867 Mbit/s
Mobile network generation4G
Microphone inNo
HDMI ports quantity0
Headphone connectivity3.5 mm
USB 2.0 ports quantity1
Device typeTablet PC
Form factorSlate
Product colorBlack, Silver
Cable lock slot typeKensington
Sustainability certificatesRoHS, ENERGY STAR
CertificationCE, CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL Listed, WEEE
Password protection typeBIOS, Supervisor, User
PlatformWindows
Trial softwareMcAfee Internet Security and Antivirus Software
Bundled softwareWaves MaxxAudio Fujitsu Plugfree Network Fujitsu Anytime USB Charge Utility Fujitsu Battery Utility Fujitsu Function Manager Fujitsu DeskUpdate Microsoft Office
Battery voltage10.8 V
Battery capacity4250 mAh
Battery life (max)9.6 h
Battery recharge time2.3 h
Number of battery cells3
AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output current3.42 A
AC adapter output voltage19 V
Storage temperature (T-T)-15 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)8 - 85 %
Operating relative humidity (H-H)20 - 85 %
Processor ARK ID88190
Processor socketLGA 1356 (Socket B2)
Intel Secure Key Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth199.3 mm
Width309.6 mm
Height12.7 mm
Weight990 g
