Fujitsu STYLISTIC Q736

Accessories for yo ur Tab let PC (opti
onal)
Ports on the keyboard docking station or power
keyboard docking station
KeyboardDockPorts
7
1
5
6
10
12
11
13
8
9
2
3
4
1 = Release b
utton
2 = Num Lock indicator (to switch virtual
numeric keypad on and off)
3 = Caps Lo
ck indicator (to switch
capita
lization function o n and off)
4 = Scroll Lock indicator (function dependent
on the application program)
5 = Batte
ry indicator of the battery in the
power
keyboard docking station (optional)
6 = Battery charging indicator of the
battery in the power keyboard do cking
station (optional)
7 = Docking p
ort for the Tablet PC
8 = DC jack (DC IN )
9 = Securit
y Lo ck device
10 = LAN port
11 = HDMI po
rt
12 = VGA m onitor po rt
13 = USB po
rts (3 x U S B 3.0)
48 Fujitsu
