Fujitsu STYLISTIC Q736 User Manual

Security functions
Removing passwords
To remove a password (without setting a new password) perf orm the following s teps:
PasswordSupervisorpasswordUser password
► Start the BIOS Setup Utility and go to the Security menu.
► Highlight the Set Supervisor Password or Set User Password field and pre ss the Enter key.

Yo u will be requested to ente r the c urrent password by the Enter Current Password prompt.
Enter New Password will appear and you will be requested to enter a new passw ord.
► Press the Enter key twice at this request.
► In the Exit menu, select the opt ion Save Changes & Exit.
► Select Yes and press the Enter key.

The Tablet PC is rebooted and the password is removed.
Removing the supervisor password simultaneously deactivates the user password.
Password protectio
n for booting the operating system
With the supervisor password you have set in the BIOS Setup Utility (see
section "
Assig ning the supervisor and user passwords", Page 74), you can
also preve nt booting of the operating system.
Operating system
Activating system protection
► Start the BIOS Setup Utility and go to the Security menu.
Operatings ystem
► Select the PasswordonBootoption and press the Enter key.
► Select the option you require (First Boot or Every B oot) and press the enter key
► Select the Save Changes & Exit option under Exit.

The Tablet PC reboots. You will be prompted to enter your password (the supervisor password).
Deactivating system protection
► Start the BIOS Setup Utility and go to the Security menu.
Operatings ystem
► Select the PasswordonBootoption and press the Enter key.
► Select the Disabled option and p ress t he Enter key.

If you do not want to change any other settings, y ou can exit BIOS Setup Util ity.
► Select the Save Changes & Exit option under Exit.

The Ta blet PC re boots. T he system is no longer password -protected.
Password protection for the ha rd disk
Passw
ordprot ection
The har
d disk p assword prevents unauthorized access to the hard disk drives
and is c
hecked internally ea ch time the system is booted. The condition for this
is that
you have assigned at least the supervisor password.
Fujitsu 75

Fujitsu STYLISTIC Q736 Specifications

General

LED backlight	Yes
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	330 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	QPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2F0
Processor cache	3 MB
Processor cores	2
Processor model	i5-6300U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel® Core™ i5-6300 Mobile Series
Processor threads	4
Processor codename	Skylake
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	42 X 24 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.8 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Internal storage capacity	128 GB
Graphics card	HD Graphics 520
Audio system	Realtek ALC255
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
WWAN	Installed
4G standard	LTE
3G standards	UMTS
SIM card type	MicroSIM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)	867 Mbit/s
Mobile network generation	4G
Microphone in	No
HDMI ports quantity	0
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Cable lock slot type	Kensington
Sustainability certificates	RoHS, ENERGY STAR
Certification	CE, CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL Listed, WEEE
Password protection type	BIOS, Supervisor, User
Platform	Windows
Trial software	McAfee Internet Security and Antivirus Software
Bundled software	Waves MaxxAudio Fujitsu Plugfree Network Fujitsu Anytime USB Charge Utility Fujitsu Battery Utility Fujitsu Function Manager Fujitsu DeskUpdate Microsoft Office
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	9.6 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	88190
Processor socket	LGA 1356 (Socket B2)
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	199.3 mm
Width	309.6 mm
Height	12.7 mm
Weight	990 g
