Fujitsu STYLISTIC Q736 User Manual

Accessories for your Tablet PC (opti
onal)
Only use M2x8 screws to secure the mountings.
► Position t he spacers beneath the mountings, position the mountings on the rear of
the Tablet PC and secure the mountings with the screws (2).
► Secure the s houlder strap on the mountings (3).
Folio case (optional)
When using the cover, we do not recommend connecting the tablet PC to the keyboard
docking station o r power keyboard docking station. Please note th at th e device cannot
be placed into the docking station in clamsh ell mode if the tablet still has its cover on.
• This folio case cont
ains magnets. Keep it away from objects that may be easily
affected by the influ
ence of m agnetism, e.g. pace m ake rs and magnetic cards.
• Make sure the device is firmly fitted into the folio case fasteners in
order to prevent it from falling out.
• The folio case is o
nly designed to safely store and transport the device.
Do not use the foli
o case f or any other purpose.
• Keep the folio case away from fire or heaters.
• Neither put the
folio case in direct sunlight nor expose it to
high temp eratu
re or humidity.
► Position the Tablet PC on the folio case as shown.
The following illustration shows you the m any ways in which the folio case can be used:
Fujitsu 61

Fujitsu STYLISTIC Q736 Specifications

General

LED backlight	Yes
Display diagonal	13.3 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	330 cd/m²
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Bus type	QPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2F0
Processor cache	3 MB
Processor cores	2
Processor model	i5-6300U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel® Core™ i5-6300 Mobile Series
Processor threads	4
Processor codename	Skylake
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	42 X 24 mm
Processor front side bus	- MHz
Processor boost frequency	3 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.8 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Internal storage capacity	128 GB
Graphics card	HD Graphics 520
Audio system	Realtek ALC255
Flash type	LED
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
WWAN	Installed
4G standard	LTE
3G standards	UMTS
SIM card type	MicroSIM
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi data rate (max)	867 Mbit/s
Mobile network generation	4G
Microphone in	No
HDMI ports quantity	0
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Cable lock slot type	Kensington
Sustainability certificates	RoHS, ENERGY STAR
Certification	CE, CB, FCC Part 15 B, cUL, FCC Part 15 C, FCC Part 15 E, FCC Part 22, FCC Part 24, FCC Part 27, ICES-003 Class B, RSS-210, UL Listed, WEEE
Password protection type	BIOS, Supervisor, User
Platform	Windows
Trial software	McAfee Internet Security and Antivirus Software
Bundled software	Waves MaxxAudio Fujitsu Plugfree Network Fujitsu Anytime USB Charge Utility Fujitsu Battery Utility Fujitsu Function Manager Fujitsu DeskUpdate Microsoft Office
Battery voltage	10.8 V
Battery capacity	4250 mAh
Battery life (max)	9.6 h
Battery recharge time	2.3 h
Number of battery cells	3
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	8 - 85 %
Operating relative humidity (H-H)	20 - 85 %
Processor ARK ID	88190
Processor socket	LGA 1356 (Socket B2)
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	199.3 mm
Width	309.6 mm
Height	12.7 mm
Weight	990 g
