Accessories for your Tablet PC (opti
onal)
1
1
1
1
► Note that there may be round adhesive covers over the inserts; if they are present, remove them.
► Position the folio cover on a on a stable, flat and clean surface, with the
inside of the folio cover pointing down.
► Disengage the Velcro and snap buttons.
► Detach the cover part from the holder part.
► Turn over the system and align the palm vein sensor (a) with th e corresponding
indent on the right side (b) o f the holder:
a
b
2
► Carefully press the system into the holder (2).
Be sure that you do not over-tighten the screws. Overtightening the
screws cou ld damage the unit.
► Turn over the folio cover and attach the system to the folio cover using the four screws
(3) provided in the kit. Use Phillips screwdriver with bit #0:
Fujitsu 67
